VAR-AM33CustomBoard
Il VAR-AM33CustomBoard Single Board Computer (SBC) può servire sia da piattaforma di sviluppo che da prodotto finale. Congiuntamente con VAR-SOM-AM33, offre una connettività ancora più ampia con interfacce aggiuntive, come Gigabit Ethernet PHY, LVDS ecc.
Specifiche
SODIMM 200 socket | Supporting the VAR-SOM-AM33 (not included) |
| Display | |
|---|---|
RGB | 18-bit RGB parallel display interface (40-pin FFC/FPC connector for 7″ WVGA LCD) |
LVDS | 18-bit |
Backlight Driver | Yes |
| Audio | |
|---|---|
Headphone | 3.5 mm connector |
Line – in | 3.5 mm connector |
| Touch Panel | |
|---|---|
Resistive | 4-wire touch panel, 4-pin FFC/FPC |
Capacitive | Capacitive touch panel, (10-pin FFC/FPC) |
| USB | |
|---|---|
USB Host | 4 ports, Type A connector |
USB OTG | Type Mini AB connector |
| Expansions | |
|---|---|
SD-CARD | SD Card Socket |
| Serial Ports | |
|---|---|
RS232 (1) | DV-9 male (DTE) |
RS232 (2) | IDC10 Header (Debug) |
RS485 | Header |
CAN Bus | CAN bus interface with isolator and driver |
| Expansion Connectors |
|---|
GPMC – Local Bus interface |
SD/MMC interface |
SPI, I2C |
UART |
GPIOs |
JTAG |
Ethernet (1) | 10/100, RJ45 |
Ethernet (2) | 10/100/1000 Mbps, RJ45 |
| Mechanical Specifications | |
|---|---|
Dimensions (W x L x H) | 12 cm x 10.5 cm x 2.4 cm |
| Electronic Specifications | |
|---|---|
Supply voltage | 7.5V -14V DC input, 2.5 mm DC jack |
RTC | Coin RTC Backup battery socket (CR1225) |
|
Documentazione
Reference Manuals
- Product Datasheet (doc v1.13)
Board Schematics
- Carrier Borad Schematics (doc v1.21)
